2SC5171 Audio Power Amplifier IC Transistor Silicon NPN Epitaxial Type 200 MHz

Product Categories

Shenzhen ATFU Electronics Technology ltd

Contact Now

Name: 2SC5171 Audio Power Amplifier IC Transistor Silicon NPN Epitaxial Type 200 MHz
Brand: TOSHIBA
Price: 1 USD

Brand Name : TOSHIBA

Model Number : 2SC5171

Certification : ROHS

Place of Origin : Original Factory

MOQ : 10pcs

Price : Negotiate

Payment Terms : T/T, Western Union，Paypal

Supply Ability : 100000pcs

Delivery Time : 1-3Days

Packaging Details : BOX

Type : Amplifiers Chip IC

Application : Power Amplifier Applications

Package : 3 Pins DIP

Feature : High transition frequency

Wide Bandwidth : 200 MHz

Series : Complementary to 2SA1930

Contact Now

2SC5171 TOSHIBA Transistor Silicon NPN Epitaxial Type Power Amplifier Applications

FEATURES

• High transition frequency: fT = 200 MHz (typ.)

• Complementary to 2SA1930

Electrical Characteristics (Tc = 25°C)

Characteristics	Symbol	Test Condition	Min	Typ.	Max	Unit
Collector cut-off current	ICBO	VCB = 180 V, IE = 0	―	―	5.0	μA
Emitter cut-off current	IEBO	VEB = 5 V, IC = 0	―	―	5.0	μA
Collector-emitter breakdown voltage	V (BR) CEO	IC = 10 mA, IB = 0	180	―	―	V
DC current gain	hFE (1)	VCE = 5 V, IC = 0.1 A	100	―	320
DC current gain	hFE (2)	VCE = 5 V, IC = 1 A	50	―	―
Collector-emitter saturation voltage	VCE (sat)	IC = 1 A, IB = 0.1 A	―	0.16	1.0	V
Base-emitter voltage	VBE	VCE = 5 V, IC = 1 A	―	0.68	1.5	V
Transition frequency	fT	VCE = 5 V, IC = 0.3 A	―	200	―	MHz
Collector output capacitance	Cob	VCB = 10 V, IE = 0, f = 1 MHz	―	16	―	pF

Absolute Maximum Ratings (Tc = 25°C)

Characteristics		Symbol	Rating	Unit
Collector-base voltage		VCBO	180	V
Collector-emitter voltage		VCEO	180	V
Emitter-base voltage		VEBO	5	V
Collector current		IC	2	A
Base current		IB	1	A
Collector power dissipation	Ta = 25°C	PC	2.0	W
Collector power dissipation	Tc = 25°C	PC	20	W
Junction temperature		Tj	150	°C
Storage temperature range		Tstg	−55 to 150	°C

Applications

• Power Amplifier Applications

• Driver Stage Amplifier Applications

2SC5171 Audio Power Amplifier IC Transistor Silicon NPN Epitaxial Type 200 MHz
